Dew Point Meter Humidity and Temperature Meter
Zoom Browse
Product Name: Dew Point Meter Humidity and Temperature Meter
Product Numbers: DPME-2102
Product Specifications: Humidity: Capacitor
Product Unit: Temperature: Resistor
Product Class:Measuring and Testing Instruments > Temperature Measuring Instrument > Dew Point Meter
Product Details
【DateTime:2018-04-12 Browse:】【Font: Big Mid Small】【Print】【Close
Dew Point Meter Humidity and Temperature Meter

Features:

*Used the exclusive MICRO-COMPUTER LSI circuit and crystal time base to offer the high accuracy measurement & fast measuring time.
* Wide measuring range & high resolution.
* Digital display gives exact reading with no guessing or errors.
* The last values/max. values/min. values of both Humidity and Temperature will be automatically
stored in memory and can be displayed by turn.
* The use of durable, long-lasting components, including a strong, light weight ABS-plastic housingassures maintenance free performance for many years. The housing has been carefully shaped to fitcomfortably in either hand.

Specification:

Display: LCD( Liquid Crystal Display)
with function annunciation
Parameters Measured:
Humidity, Temperature, Wet Bulb
Temperature, Dew Point Temperature
Sampling Time : 0.4 second
Memory: Last values, Max. Values, Min values
Battery : 4x1.5v AAA (UM-4) battery
Size: 140x70x30 mm
Weight: 145 g / 0.32 lb (Not Including Batteries)

Sensor type:
Humidity: Capacitor
Temperature: Resistor
Dew Point Temp. range:
       -40°C~40°C (-40°F~104°F)
Dew Point Temp. resolution: 0.1°C
Dew Point Temp. accuracy: ±1°C
R.H range: 10%~95%
R.H resolution: 0.1%R.H
R.H accuracy: 2.5 %±1%R.H
Temp. range: -10°C~60°C (14°F~140°F)
Temp. resolution: 0.1°C / 0.1°F
Temp. accuracy: ±0.5°C
Wet Bulb Temp. range: -10°C~60°C (14°F~140°F)
Wet Bulb Temp. resolution: 0.1°C / 0.1°F
Wet Bulb Temp. accuracy: ±0.5°C
