Features:
-Real-time temperature measurement
-Low Cost, affordable, Economical type
-Widely used in school, large show, subway, airport, customs
-2-meter drop resistance
-More sensitive more accurate
-Real-time video,all of the testing process are documented
Specification
|
Item
|
TE-W1
|
|
Detector
|
Detector type
|
Uncooled FPA
|
|
Resolution
|
160×120
|
|
Image performance
|
FOV/Minimum focal distance
|
25°×19°/0.1m
|
|
Spatial resolution
|
2.72mrad
|
|
Thermal sensitivity
|
≤0.06℃@30℃
|
|
Frame rate
|
50/60Hz
|
|
Focus
|
Manual focus
|
|
Spectral range
|
8-14um
|
|
Built-in visual camera
|
1.3M resolution，CMOS module
|
|
Image display
|
LCD screen
|
3.5” TFT color LCD，640×480 resolution
|
|
Color palette
|
11 color (optional)
|
|
image adjustment
|
Auto/manual contrast, brightness
|
|
Measurement
|
Measuring range
|
20℃- 50℃
|
|
Accuracy
|
±0.6℃
|
|
Measurement correction
|
Auto/manual
|
|
Measuring mode
|
Up to 4 movable spots , Up to 3 movable areas(the highest temperature, the lowest temperature capture, average temperature measurement), Line profile, Isotherm, Temperature difference, Temperature alarm (voice, color)
|
|
Setup function
|
Date/time temperature unit ℃/℉/K, language
|
|
Emissivity correction
|
Variable from 0.01 to 1.0
|
|
Background light correction
|
Auto
|
|
Atmospheric transmittance correction
|
Automatic correction according to user input object distance, relative humidity, ambient temperature
|
|
Image storage
|
Memory card
|
8G Micro SD（TF）card，max 16G
|
|
Saving method
|
Manual/Auto single file saving, IR and visual image link saving
|
|
File format-thermal
|
JPEG format, with original thermal data
|
|
File format-visual
|
JPEG format
|
|
Voice annotation
|
Input via built-in microphone up to 60 seconds of digital voice clip per image stored with image
|
|
Laser pointer
|
Laser pointer
|
The class2，1mW/635nm red
|
|
Power supply system
|
Battery type
|
Li-Ion, rechargeable
|
|
The operating time of battery
|
The 4 hours continuous operating time
|
|
Rechargeable type
|
Intelligent charge or power adapter 12V (optional) to random charge
|
|
Saving method
|
Auto sleep, auto shutdown
|
|
Environment
|
Operating temperature
|
0℃-+42℃
|
|
Storage temperature
|
-40℃~+70℃
|
|
Humidity
|
≦95％
|
|
Encapsulation
|
IP54
|
|
Anti-shock
|
25G，IEC68-2-29
|
|
Anti-vibration
|
2G，IEC68-2-6
|
|
Drop
|
2meters
|
|
Physical characteristic
|
Weight
|
0.98Kg
|
|
Dimension
|
230mm×105mm×245mm
|
|
handrail
|
Both sides can be saved
|
|
Tripod
|
1/4″-20-UNC
|
|
Interface
|
Power supply interface
|
Yes，DC 12V
|
|
Memory card slot
|
Micro SD（TF）slot
|
|
Video output
|
Yes，PAL/NTSC
|
|
Date output
|
Mini-USB，The image, measurement date, voice can be transmitted to computer
|
