Features:
-Low cost Cheap products
-infrared image detector
-High porformance
-Portable for home user or hobbyist
-Different palette selectable
Specification
Display: 2.4 inch full viewing angle high-resolution color screen
Resolution: 32 * 32
Measuring Mode: Thermopile
Resolution of visible image: 0.3 mega pixels.
Total Pixel: 1024
FOV/Shortest Focal Length: 33*33
Thermal Sensitivity: 0.5C
Detecting Range: -20C to 300C(-4F to 572F)
Measuring Accuracy: ±2% or ±2C(±4F)
Wavelength Range: 8-14μm
Emissivity: 0.1-1.0 Adjustable
Image Frequency: 6HZ
Focus Mode: Fixed
Palette: Iron red,rainbow,rainbow high contrast,gray scale(white glow) and gray scale(black glow)
Vision Option: 5 kinds of full infrared to the full visual, mixing visible and infrared.
Image Storage: SD card(4G)
File Format: bmp
Set Control: Unit Adjustment/Language/Date Time Format/automatic shut down
Battery Type: 4 * 1.5V AA battery (Not Included)
Battery Life: 6 Hours
Auto Power-off Time: 12 Minutes
Certificate: CE, RoHS
Operating Temperature: -5C to 40C (23F to 104F)
Storage Temperature: -20C to 50C(-4F to 122F)
Relative Humidity: 10%RH to 80%RH
Item Size: 21.2 * 9 * 6.2cm / 8.3 * 3.5 * 2.4in
Item Weight: 231.2g / 8.2oz
Package Size: 27 * 19 * 11cm / 10.6 * 7.5 * 4.3in
Package Weight: 927g / 32.7oz
