----Dual-core measurement unit

    ----Long-term stability and repeatability.
    ----Accuracy: 0.05°

    ----Repeatability: 0.05°

    ----Resolution: 0.01°
    ----Measuring range: ±90°

    ----Fast response

    ----Data hold on function
    ----Absolute/Relative measurement can switch

    ----Both sides and bottom can measure
    ----Double benchmark strong magnet installation

    ----Working Temperature : -20°~ +65℃
    ----Auto-angle interleaved compensation function

    ----Auto temperature drift compensation
    ----User can calibrate by himself

    ----Built-in recharge industry battaries
    ----Night vision fours colors screen

    ----IP54 protection class
    ----°/mm Dual units switch function

    ----100g High anti-impact

Application :
    ----Building construction

    ----Automobile four-wheel testing
    ----Road slope

    ----Machinery installation

    ----Piping installation

    ----Industrial platform
    ----Turntable testing

    ----Cloud deck angle detection

    ----Production jig

    ----Medical instruments

Angle Measuring range	+/-90 Degree		°
MM measuring range	0-+/-999.9		mm
Meausring axis	X Y Axis
The highest meausring accuracy	+/-0.05		°
Angle Measuring resolution	0.01		°
MM measuring accuracy	0.9		mm
MM measuring res	0.17		mm
LCD
LCD visible area size	L40*W32		mm
Working temperature	-10°~ +70℃		°/℃
Working humidity	85		%RH
Power supply	3.7VCharging Lithium battery		V
Ideal charging time	3		h
Battery sustainable charging times	8(+/-0.5)		h
Connect plug in	Standard 5Pin USB connector
Shock resistance	10g@11ms, 3Times/Axis(half sinusoid)
Shock impact	10grms, 10～100Hz
Weight	125		g
Waterproof grade	IP54
Material	Aluminum alloy
Size	L83*W53*H19.2mm		mm
