The force gauge has advantages of high precision, easy operation and carry. Whats more, it has kinds of testing modes, convenience for conner and it can store and input data to computer for statistical analysis as well as constitutes testers with different functions, combinating with test-beds and clamp. Users can input local acceleration of gravity value to make test more precise.



1. CE Certificate
2. One year Warranty
3. Can connect to PC
4. 6 digits screen display
5. N , kg and lb three units convertible

1. High precision and high resolution.

2. Five testing modes and three display methods for selection--enhancetesting efficiency to the maximum extent

3. N (Newton), kg (Kilogram) and lb (Pound) three measuring units for selection and conversion.

4. Setting function of gravity acceleration---User can input at your option the accurate value of gravity acceleration at the using place so as to make the testing and unit conversion be more accurate.

5. Function of peak value maintaining. Maintain the display of peak value until manual zero clearing.

6 .Automatic peak function. Maintain the display of peak value for 2 seconds and then release automatically.

7. Max and min and comparison value can be set for statistic analysis. The buzzer will alarm if exceeding comparison value.

8. Data storage function. 896 testing values can be stored.

9. Data output function. The data can be input into computer through data line for various analyses.

10. Environmental protection. The device will automatically stop if no operation within 10 minutes.

11. High quality chargeable power supply. The charging voltage is avai-lable from 100V to 240V, which can accommodate most areas in domestic and at abroad.

12. 2 sets mounting dimensions, it is applied for most testing platforms domestically and easy for users to install it to platform.

13. Special testing function of make-break ability of switch contact to make the make

break testing be more accurate.

14. 6 digits large screen display.

15. Synchronous measuring softwarecan connect computer measuring, the computer display measuring graph and the detailed testing records,and can preserve, print ,make analysis,input speed, area, displacement, pressure. ( chosen functiondetails see CD data )

16. Contact control signal outputsetting comparative value,when the Measuring value is over comparative value, output signal control circuit Breakers make-and break, thus realize the function of stop electromotor, And control automatically; it is also can be used for realize other control Functions.





Part No.	Range	Reolutions	Sensor Type	Accuracy	Size
FOGA-3401	1KN	1N	S type external	+/-0.5%	230*66*36
FOGA-3402	2KN	1N	S type external	+/-0.5%	230*66*36
FOGA-3403	3KN	1N	S type external	+/-0.5%	230*66*36
FOGA-3404	5KN	1N	S type external	+/-0.5%	230*66*36
FOGA-3405	10KN	0.01KN	S type external	+/-0.5%	230*66*36
FOGA-3406	20KN	0.01KN	S type external	+/-0.5%	230*66*36
FOGA-3407	30KN	0.01KN	S type external	+/-0.5%	230*66*36
FOGA-3408	50KN	0.1KN	S type external	+/-0.5%	230*66*36
FOGA-3409	100KN	0.1KN	S type external	+/-0.5%	230*66*36
FOGA-3410	200KN	0.1KN	Cylindrical or spoke(external)	+/-1%	230*66*36
FOGA-3411	300KN	0.1KN	Cylindrical or spoke(external)	+/-1%	230*66*36
FOGA-3412	500KN	0.1K	Cylindrical or spoke(external)	+/-1%	230*66*36
FOGA-3413	1000KN	1KN	Cylindrical or spoke(external)	+/-1%	230*66*36
