China Insert Type Digital Ultrasonic Flowmeter_

China Insert Type Digital Ultrasonic Flowmeter

Product Name: China Insert Type Digital Ultrasonic Flowmeter

Product Numbers: ULFL-2329

Product Specifications: 0.01～12 m/s

Product Unit: ultrasonic flowmeter

Product Remark: Repeatability: 0.15%

Product Class:Measuring and Testing Instruments > Flow Meters > China Ultrasonic Flowmeters

Product Details

【DateTime:2012-01-10 Browse:】【Font: Big Mid Small】【Print】【Close】

China Insert Type Digital Ultrasonic Flowmeter:

1. Transducer cable anti-pressure intensity :800N

2. Calibration and maintain without stopping the production

3. Positive and negative measurement. accummlated flow data

4. 8.8 million data storeage.

5. Cut-off Power flow compensation

6. Signal attenuation: –90db/100M

7.Pipe: 50 mm～5000 mm

8.Exposion proof: Ex d IIB T4

Transmitter:

Flow range: 0.01～12 m/s

Accuracy: 0.5% of reading or 1.0%
Repeatability: 0.15%
Communications: RS232 / RS485
Power Supply: 90~245VAC 10~36VDC
Weight: 4.8lbs
Outputs:4~20mA, maximum 750 ohms

Interface: RS232/RS485. Modbus
OCT pulse, 0~10 KHz
Relay output 1Hz

IP65 protection

Working temperature: -40℃～+60℃

Display: 20*2 Dot-matrix characters

Support SD card

Storeage: 8.8 million group. including: instantaneous flow meter, positive and negtive flow meter, flow speed, date etc.

China Insert Type Digital Ultrasonic Flowmeter

Suitable to single liqud. without impurity, floated solids,

Pipe: carbon steel, stainless steel, PVC, cast iron, aluminum, copper pipe.
