For normal solution for measuring the conductivity, especially in the areas of education and research used.

1. Meter meets with the requirement of international GLP standards. Its features up to automatic calibration, automatic temperature compensation, data storage, timing measurement, clock display, RS-232 output, function setting and self-diagnose etc.
2. There are three different measurement modes: stable display mode; time measurement mode; continuous measurement mode.
3. Equips Conductivity/ATC electrode. Its measurement result is fast and precise.
4. Adopt advanced and original conductivity measurement technology, use 1 pc of conductivity electrode (K=1), it can meet measuring accuracy requirement for range within 0.5μS/cm ~ 200mS/cm by using only one-point calibration.
5. Ability to switch among conductivity, TDS, salinity and resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
6. Meter has the only product serial number.
7. Dustproof and waterproof meter meets IP54 standards. All sockets are seal protected by the silica gel caps.



Conductivity	Measuring range           Resolution Accuracy Temp. compensation range Electrode constant Reference temperature	Conductivity:(0.00~20.00)μS/cm (20.0~200.0)μS/cm (200~2000)μS/cm  (2.00~20.00)mS/cm (20.0~200.0)mS/cm Resistivity:(0 ~100)MΩ·cm TDS:  (0 ~ 100)g/L Salinity: (0 ~ 100)ppt 0.01/0.1/1μS/cm  0.01/0.1/1 mS/cm Meter:+/-0.5% FS,connect meter with electrode:+/-0.80% FS (0 ~ 50)℃(automatic ) 0.1 / 0.5 / 1 / 5 / 10 / 50 / 100  cm-1 25℃, 20℃ and 18℃
Temperature	Measuring range Resolution Accuracy	-10℃~110℃ 0.1℃ 5~ 60℃range:+/-0.4℃  other range+/-0.8℃
Other Technical Parameters:	Data storage Storage content   Power Communication connector Size and weight Quality and safety certification	300 groups Measuring value series number, measuring value, temperature, ATC or MTC state, measuring date and time DC9V/300mA RS232 160 * 190 ×*70mm/880g ISO9001:2008, CE and CMC
Working Condition	Environment temperature Environmental humidity IP rating	5 ~ 35 ℃(0.01grade)15 ~ 30 ℃(0.001grade) ≤75% IP54 Dustproof and waterproof

Standard Kits;

1. Model PHME-513 lab conductivity meter 1 unit
2. Model 602 flexible electrode holder 1pc
3. 2301T-M plastic pH/ATC three-in-one combination electrode 1 pc
4. 1413μS/cm conductivity standard solution (50mL) 2 bottles
5. 9V power adapter 1pc
6. RS-232 communication cable 1pc
7. MP513 communication software CD 1pc
8. Operation manual 1 unit
9. Brief operation manual 1 unit
10. Packing List 1 pc
