| Parameters |
AC resistance, X, Z, θ, L, DC voltage |
AC resistance, X, Z, θ, L, DC voltage |
| Accuracy |
Resistance: 0.5% Voltage: 0.3% |
Resistance: 0.5% Voltage: 0.3% |
| Range |
Resistance: 0.1mΩ～300Ω Voltage: 10mV ~800V |
Resistance: 0.1mΩ～300Ω Voltage: 10mV~400V |
| Signal Source |
AC 1kHz open-circuit voltage < 20mV measurement current: 1mA/0.1mA/10nA/5nA |
AC 1kHz open-circuit voltage < 20mV measurement current: 1mA/0.1mA/10nA/5nA |
| Range |
Automatic or manual with 4 ranges |
Automatic or manual with 4 ranges |
| Speed |
20 times/second, 6 times/second, 1 time/second |
20 times/second, 6 times/second, 1 time/second |
| Result Display |
Show, ΔABS, Δ%, θ,sorting results |
Show,ΔABS, Δ%, θ,results |
| Display Max |
Resistance: 3200 Voltage: 7800 |
Resistance: 3,200 Voltage: 8,000 |
| Adjustment |
Short-circuit reset for each range, REL function |
Short-circuit reset for each range, REL function |
| Comparator |
30 groups record, HI/IN/LOW/GD/NG sorting result display and output, beep is adjustable |
30 groups record, HI/IN/LOW/GD/NG sorting result display and output, beep is adjustable |
| Trigger |
Internal, Manual, External (optional) |
Internal, Manual, External (optional) |
| Interface |
RS-232C |
RS-232C |
| Voltage |
Voltage: 198V AC - 240V AC Frequency: 50Hz |
Voltage: 198V AC - 240V AC Frequency: 50Hz Power: Max 15VA |
| Package |
264mm (Width)x107mm (Height)x350mm (Depth) 4kg |
264mm (Width)x107mm (Height)x350mm (Depth) 4kg |
| Accessory |
ATL505 Kelvin Clip |
ATL505 Kelvin Clip |
| Optional Accessories |
ATL506A: test probe ATL506: test leads |
ATL506A: test probe ATL506: test leads |
| |
Detection of damage test wire, four-color vacuum fluorescent screen VFD display, keypad lock and data hold function |
Detection of damage test wire, four-color vacuum fluorescent screen VFD display, keypad lock and data hold function |
