ISO2400-1972E IIW-Type 1 Test Calibration Block Ultrasonic Thickness
Zoom Browse
Product Name: ISO2400-1972E IIW-Type 1 Test Calibration Block Ultrasonic Thickness
Product Numbers: ULCA-20008
Product Unit: Standard made to - BS 2704
Product Remark: Carbon Steel, 12.5mm thick with 1.5mm hole
Product Class:Measuring and Testing Instruments > NDT Instruments > Calibration Block
Product Details
【DateTime:2021-04-20 Browse:】【Font: Big Mid Small】【Print】【Close】

ISO2400-1972E IIW-Type 1 Test Calibration Block


Small calibration block for on-site checking of miniature shear wave probe index, time base, beam angle and gain, engraved reference mark scales from 35 to 75 degrees. can provide V2 calibration block based on BS2704 and ISO 7963.

Specification:

Standard made to - BS 2704 (Tolerance +/- 0.1mm)

Blocks available off the shelf are

Carbon Steel, 12.5mm thick with 1.5mm hole

Carbon Steel, 20mm thick with 3mm hole

Stainless Steel, 12.5mm thick with 1.5mm hole
