Model

UTI160C

Basic function

Field of view / minimum imaging distance

20 ° X15 ° / 0.1m (optional variety of lenses)

High temperature sensitivity

≤ 0.08° @ 30°

Detector Type

Uncooled

Graphics mode

IR / visible / PIP / fusion

Visible resolution

640 × 480 (full color)

Resolution

160X120

Working band

8 ~ 14um

Focus mode

Manual Focus

Spatial resolution

2.2mrad

Image Mode

Infrared (red iron oxide, anti-iron oxide red, rainbow, medical, incandescent, black fever)

LCD

2.5 TFT screen

Special  Feature

Video output

Composite video in PAL (50Hz) or NTSC (60Hz)

Temperature range

-20°to +300° (extended to 1500°)

Temperature measurement accuracy

± 2°, ± 2% (of reading in ± 30°)

Temperature measurement mode

4 movable points and high temperature / lowest temperature capture, isothermal analysis

Control settings

Language / time / pseudo-color / unit

Temperature difference calculation

√

Parameter correction

Emissivity, ambient temperature, distance, relative humidity

Type

Removable 2GB removable SD card (can store 16,000 standard infrared thermal image)

File Format

The UIR, the visible light image file format CCD

Lighting

√

Laser pointer

√

Alarm settings

√

Battery type / working time

Rechargeable lithium battery / 2.5 hours

Power-saving mode

Sleep mode

Special technical specifications

Working temperature: -15°to +50°; Storage Temperature: -40 ° to +70°; humidity: ≤ 95%; IP54 Shock (operating): 25G / shock resistance: 2.5G; software analysis report
