China Camara Termografica
Es una nueva cámara infrarroja de la marca GUIDE. Entra exitosamente en el medio por su gran desempeño. Ha sido diseñada para condiciones de trabajo rudo y para ser operada aun por operarios inexpertos.
Es resistente al impacto y es fácil de operar, incluso los empleados en capacitación podrán realizar inspecciones fácilmente con una sola mano.
La cámara cuenta con la más nueva tecnología de fusión de imagen infrarroja que le permite localizar zonas específicas con alta eficiencia haciendo sencillo su trabajo
|
Imaging Performance
|
UTI380A
|
|
Campo de visión
|
24° x 18°, 12°x9°, 48°x36°
|
|
Spatial resolution
|
1.3 mrad for 24°x18°
|
|
Minimum Focus Distance
|
0.5m
|
|
Sensibilidad Térmica(NETD)
|
0.05 @ 30° C
|
|
Detector Data Acquisition
|
60Hz
|
|
Focus
|
Manual
|
|
Detector type
|
UFPA,384X288
|
|
Spectral band
|
8~14 um
|
|
On camera operating modules
|
Full thermal, full visual light or PIP
|
|
Visible light camera
|
640 x 480pixles/full color
|
|
Temperature Measurement
|
|
|
Range 1
|
-20° C to 250°C
|
|
Range 2
|
200° C to 1000 °C
|
|
Range 3
|
800° C to 1500 °C
|
|
Accuracy
|
±2 °C or 2%
|
|
Measurement modes
|
analysis up to 10 spots, auto tracking, area analysis, isotherm analysis, line profile
|
|
Temperature alarm
|
max/min, isotherm alarm
|
|
Correction
|
emissivity (0.1 to 1.0,0.01 increments), ambient temp., distance, relative humidity
|
|
Digital Display
|
3.5" LCD integrated with remote control
|
|
LCD backlight
|
CCFL
|
|
Video output
|
NTSC 60Hz / PAL 50 Hz composite video
|
|
View Finder
|
640X 480 full color
|
|
palettes
|
6
|
|
Image and Data Storage
|
|
|
Storage Medium
|
Mini SD card/2GB
|
|
File format
|
14 bit measurement data included, SAT format
|
|
Voice annotation
|
40S with headset, saved with thermal image
|
|
Software
|
|
|
Interfaces and Software
|
SatIrReport Standard, SatIrReport Professional, SatIrReport USB
|
|
USB 2.0
|
Transfer thermal video with 14 bit measurement date to PC
|
|
Illuminator
|
Yes
|
|
Laser
|
635 nm red, Class II, laser dot visible on screen when blending thermal and visible images
|
|
Power, Battery Life
|
|
|
battery type
|
Rechargeable Lithium Battery
|
|
battery operating time
|
2.5 Hours continues
|
|
battery charging
|
1 bay intelligent charger powered via AC outlet
|
|
Power saving
|
Automatic shut down and sleep mode
|
|
Environmental and Mechanical Design
|
|
|
Operating temperature
|
negative 20 to 50 C
|
|
storage temperature
|
negative 40 to 70 C
|
|
relative humidity
|
10% to 95%, non-condensing
|
|
water and dust resistant
|
IP54
|
|
Shock
|
Operational: 25G
|
|
Vibration
|
Operational: 2G
|
|
weight (battery included)
|
700g
|
|
size
|
215mm x 80mm x 219mm
|
|
Tripod mounting
|
1/4"_20
|
