Radius Gauge Sets
Zoom Browse
Product Name: Radius Gauge Sets
Product Numbers: RAGE-004
Product Specifications: 0.5-13
Product Unit: 1/64 to 1/2"
Product Class:Measuring Tools > Pitch Feeler Gauge > Radius Gauge
Product Details
【DateTime:2009-12-12 Browse:】【Font: Big Mid Small】【Print】【Close
 Order No
  Range
 Size of blade
 Quantity  of blade
 Handle
 RAGE-004
 0.5 to 13mm
 0.5, 1, 1.5, 2, 2.5, 3,  3.5,  4, 4.5, 5, 5.5, 6,  6.5, 7,  7.5, 8, 8.5, 9,  9.5, 10,  10.5, 11,  11.5, 12, 12.5,  13mm
  26pcs
  With
  RAGE-005
 0.5 to 15mm
 0.5, 1, 1.5, 2, 2.5, 3,  3.5,  4, 4.5, 5, 5.5, 6,  6.5, 7, 8,  9, 10, 11,  12, 13, 14,  15mm
  22pcs
  With
  Code
 Range
 Size of blade
 Quantity  of blade
 Handle
  IRGS-001
 1/64 to 1/2"
 1/64, 1/32, 3/64, 1/16,  5/64, 3/32, 7/64, 1/8,  9/64, 5/32, 11/64,  3/16,  7/32, 15/64,  1/4, 17/64,  9/32,  5/16, 11/32, 3/8,  13/32, 7/16, 15/32,  1/2"
  25pcs
  With
  IRGS-002
 9/16 to 1"
 9/16, 5/8, 11/16, 3/4,  13/16, 7/8, 15/16, 1"
  8pcs
  Without
  IRGS-003
 1-1/16" to 1-1/2"
 1-1/16, 1-1/8, 1-3/16,  1- 1/4, 1-5/16, 1-3/8,  1- 7/16, 1-1/2"
  8pcs
  Without
  IRGS-004
 0.010  to 0.5"
 0.010, 0.015, 0.020,  0.025, 0.030, 0.040,  0.050, 0.060, 0.070,  0.080, 0.090, 0.100,  0.12, 0.14, 0.16, 0.18,  0.20, 0.22, 0.24, 0.26,  0.28, 0.30, 0.35, 0.40,  0.45, 0.50"
  26pcs
  With
  IRGS-005
 0.55 to 1"
 0.55, 0.60, 0.65, 0.70,  0.75, 0.80, 0.85, 0.90,  0.95, 1"
  10pcs
  Without

radius gauge
