Metric Pin Gage Sets With Handle
Part NO: GB-62101
Features:
----Class ZZ(0.005mm tolarence).
----0.02mm size increments on set members.
----60/62HRC
----With Handle
----Supplied with Fitted Box
----Checking locations.
----Measuring hole sizes and depths.
----GO and NO GO gaging.
----Setting micrometers.
----Checking distances between holes.
Specifications
| Plus(+0.005mm) |
Minus(-0.005mm) |
|
|
| Order No. |
Order NO. |
Pcs |
Range(mm) |
| GB-62101 |
GB-62201 |
55 |
0.20-1.28 |
| GB-62102 |
GB-62202 |
55 |
0.21-1.29 |
| GB-62103 |
GB-62203 |
185 |
1.3-4.98 |
| GB-62104 |
GB-62204 |
185 |
1.31-4.99 |
| GB-62105 |
GB-62205 |
250 |
5.00-9.98 |
| GB-62106 |
GB-62206 |
250 |
5.01-9.99 |
| GB-62107 |
GB-62207 |
200 |
10.00-13.98 |
| GB-62108 |
GB-62208 |
200 |
10.1-13.99 |
| GB-62109 |
GB-62209 |
125 |
14.00-16.48 |
| GB-62110 |
GB-62210 |
125 |
14.01-16.49 |
| GB-62111 |
GB-62211 |
125 |
16.50-18.98 |
| GB-62112 |
GB-62212 |
125 |
16.51-18.99 |
| GB-62113 |
GB-62213 |
100 |
19.00-20.98 |
| GB-62114 |
GB-62214 |
100 |
19.01-20.99 |
| GB-62115 |
GB-62215 |
75 |
21.00-22.48 |
| GB-62116 |
GB-62216 |
75 |
21.01-22.49 |
| GB-62117 |
GB-62217 |
75 |
22.50-23.98 |
| GB-62118 |
GB-62218 |
75 |
22.51-23.99 |
| GB-62119 |
GB-62219 |
75 |
24.00-25.48 |
| GB-62120 |
GB-62220 |
75 |
24.01-25.49 |
