Part No:  CDME-1132

- More light, more color difference formula to meet customer demand for more measurements.
- High-end color difference meter  to fill the gaps in the field of color difference meter high repeat accuracy, repeatability of Δ<0.03;
- High-end color difference meter with 8 standard light source, to fill gaps in the domestic color difference meter in the multiple light sources;
- High-end color difference meter with 8 kinds of color difference formula, to fill the domestic blank color difference evaluation in various ways;
- High-end color difference meter  the exclusive release color simulation function.



Specifications:

Display Mode	CIELAB, CIELCH, CIEXYZ, CIELUV, HunterLAB, sRGB
Color Difference Formula	Delta E*ab,  Delta ECMC,  DeltaEISO,  DeltaECIE94,  DeltaEFCMⅡ,  DeltaELuv,  DeltaEhunter, DeltaEsRGB
Yellowness and Whiteness	Ganci whiteness, ISO brightness,  YI yellowness
Illumination Condition	CIE Recommendation: 8/d
Light Source	LED blue excitation
Sensor	Photodiode array
Measurement Caliber	φ4mm
Measurement Condition	Observer:CIE 10 Degree Standard observer   Light source: A C D50 D65 F2(CWF) F7 F11(TL84) F12(U30)   Contain light way: SCI SCE
Measurement Range	L: 0 to 100
Repeated Accuracy	Delta E<0.03 (take the deviation average after 30 times measuring the whiteboard)
Table Difference	Delta E<0.2
Measurement Interval	0.5 Sec.
Average Measuring Function	Average measuring frequency: 1-32 times
Color Simulation Function	yes
Storage Capacity	Type sample data : 100 with testing sample data: 20000  Whiteness/yellowness data: 200
Language Patterns	English/Simplified Chinese/Traditional Chinese
Quality Control Software	<Color-Analysis System> software
Battery Charging Time	8 hrs
Battery	Li-ion battery, 5000 times Measurement
Lifetime of Bulb	5 years more than 1.6 million measurements
Display Screen	TFT true color 2.8inch@(16:9)  Resolution ratio:400x240
Interface of External	USB2.0 (USB-B)- data communication with <color analysis system>software                      RS-232 (115200bps)- connected with micro printer
Working Temperature Range	0-40 Degree（32℉-104℉）
Storage Temperature Range	-20- 50 Degree（-4℉-122℉）
Humidity Range	Relative humidity less than 85%,without condensation
Weight	700g
Size	199*68*90mm
Size of Exterior Package	400*240*340mm
Standard Accessories	Standard whiteboard/Standard black cavity/3000mAH Li-ion battery/AC adapter/USB Data line/CD<Color analysis software>/User manual/Warranty card
Optional Accessories	Flour measuring device/Liquid measuring device/Micro printer
