*Newly Designed look,

*Low power consumption,
*Waterproof, touch Control button , easy to use.
*Automatic identification probes, may manually choose probe.
*Two measurement modes: the basic mode, monitoring mode,
*So as to facilitate customer  monitoring measurements.
*Data transmission, RS232 interface with micro printer or PC  Connection.
*Five kinds of probes can be arbitrarily chosen match

Technical  parameters:
*Measuring range 0.65-360mm（45# Steel）
*Accuracy 0.01mm
*Error value
(H is thickness of the material) H<10mm  ±0.05mm
                         H≥10mm   ±（0.01+H/200）
*Temperature of tested material -20degree ~550 degree（depending on the probe)
*Velocity range 1000~9990 m/s
*Probe Standard equipped with 5MH probe, the probe can also choose the others
*Data processing Can store 600 measurement data, can be connected to a printer and pc
*Power 2 pieces of AA batteries
*Auto power off Automatic power standby after five minutes
*Display Screen Black and white display Liquid crystal(LCD), 100 * 100, automatic backlight
*Show information Coupled instructions, measurement rate
*Operating environment Temperature -10 degree ~60 degree, relative humidity <90 %



1. Host                                         1

2. The probe (φ8 probe)          1

3. Couplant                                1

4. Manual     　                           1

 5.Warranty card, certificate     1

6. Two AA batteries                   1

7. Suitcase                                  1
8. Step test block (optional)     1
