Features:
Electromagnetic force sensor,
Builtin calibration weight balance,
Easy calibration at any time,
With overload / underload alarm,
Full range peeled cumulative / regressive,
Weighing at the end of hook functions can meet the demand for a variety of laboratory quality analysis .
Counting number function
Weighing moving articles function
Unit system function
LCD display
Background light
Small volume
Auto-adjustment
Outside adjust poise
Alert on overload and short load
Accumulating addition / reduction
Function chooses between weighing functions and weighing units
4 kinds of weighing functions
10 kinds of weighing units
Output data or print
Weigh with bottom hook to perform precision weighing or weighing of magnetic articles
Built-in RS-232 interface can be conntected with outside equipment
Specification:
| |
ANBA-4001 (Double Capacity)
|
|
Sensor
|
Bottom hook
Magnetic Sensor |
|
|
|
Capacity
|
30g/180g
|
|
|
|
Readablity
|
0.00001g(0.01mg)/0.0001g(0.1mg)
|
Min Capacity
|
0.005g(5mg)/0.05g(50mg)
|
|
Repeatablity
|
≤±.0001g(0.1mg)
|
Linearity
|
≤±0.0002g(0.2mg)
|
| Error |
≤±0.0002g(0.2mg)
|
Stablilization Time
|
<3 Seconds
|
|
Pan Size
|
Φ90mm
|
Shield Dimensions
|
185×155×210 mm
|
|
Overal Dimensions
|
410×195×280 mm
|
Package Size
|
570×370×450 mm
|
|
Working Temperature
|
0℃<～45℃
|
Humidity
|
20%RH—85%RH
|
|
Calibration
|
Auto Self Calitration System and manual poise
|
|
|
|
weights
|
Built in
|
Calibration Weight
|
Standar Ring Weight (Grade F1 100g)
|
|
N.W
|
10.1kg
|
G.W
|
11.5kg
|
|
Power
|
AC220V±10\50Hz
|
power consumption
|
<20W
|
|
Display
|
Blue LCD
|
|
|
|
Interface
|
RS232(option
|
|
|
|
Shield
|
with Three Doors
|
|
|
|
Key
|
6
|
Function
|
Power/Tare/Auto Calibration
|
